45-204 HYDRAULIC PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1 10-554 Steering Cylinder 2
18-154 Rod End 2
2 45-136 Hydraulic Hose, 24" 1
3 34-103 Orbitol 1
4 45-024 Hydraulic Hose, 37�5" 1
5 45-029 Hydraulic Hose, 27" 1
6 45-028 Hydraulic Hose, 31�5" 1
7 13-729 2-Bank Hydraulic Valve 1
8 45-030 Hydraulic Hose, 47" 1
9 45-031 Hydraulic Hose, 50" 1
10 43-150 Rake Cylinder 1
42-040 Yoke End 1
11 45-382 Cooler 1
12 45-186 Hydraulic Hose, 70" 1
13 45-032 Hydraulic Hose, 15�5" 1
14 45-187 Hydraulic Hose, 58" 1
15 76-238 Front Wheel Motor 1
16 45-027 Hydraulic Hose, 40" 1
17 45-023 Hydraulic Hose, 45" 1
18 45-025 Hydraulic Hose, 29" 1
19 23-006 Oil Filter 1
23-031 Replacement Filter only 1
20 8832-37
3
/
4
" Suction Hose, x 37" 1
18-040 Hose Clamp 2
21 45-373 Piston Pump 1
22 45-365 Hydraulic Hose, 16" 1
23 45-385 Hydraulic Hose, 11�5" 1
25 45-041 Right Upper Steel Tube 1
26 45-065 Right Wheel Motor w/ Brake 1
27 45-040 Right Lower Steel Tube 1
28 18-170 Tee 2
29 45-038 Left Lower Steel Tube 1
30 18-337 Tee 1
31 45-037 Hydraulic Hose, 12�5" 1
32 45-366 Hydraulic Hose, 54" 1
33 45-039 Left Upper Steel Tube 1
34 42-005 Oil Tank 1
13-747 Filler Breather 1
35 45-066 Left Wheel Motor w/ Brake 1
HYDRAULIC PRESSURES
Piston Pump Displacement �913 in
3
Charge Pump Displacement �33 in
3
/rev
Pump Input Speed (up to) 3300rpm Max� Inlet Vacuum 5 in� Hg
Max� Operating Pressure 3000 peak psi Max� Case Pressure 25 psi
Implement Setting 345 psi Relief Valve Pressure (set at) 1230 psi
13-729 Hydraulic Valve (2 bank) 900 psi
