33
Parts
18HP ENGINE PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1 45-058 Air Filter Mount 1
2 42-834 Air Cleaner 1
42-076-03 Replacement Filter 1
42-834-03 Safety Filter 1
3 18-116 Hose Clamp 4
4 8959-26 Flex Hose, 26" 1
5 45-118 Throttle Cable 1
6 80-020 Choke Cable 1
7 42-776 Air Cleaner Hose Sleeve 1
8 27-113 Rubber Elbow 1
9 45-383 Cooler Mount 1
10 45-382 Cooler 1
11 18-410 Connector 2
12 HB-516-18-075 Hex Bolt,
5
/
16
-18 -
3
/
4
1
HW-516 Flat Washer,
5
/
16
1
HNFL-516-18 Flange Whiz Lock Nut,
5
/
16
- 18 1
13 HB-38-16-225 Hex Bolt,
3
/
8
- 16 x 2
1
/
4
4
HW-38 Washer,
3
/
8
4
HNTL-38-16 Top Lock Nut,
3
/
8
- 16 4
14 20-618 Rubber Insulators 4
HB-516-18-075 Hex Bolt,
5
/
16
- 18 x
3
/
4
8
HNFL-516-18 Flange Whiz Lock Nut,
5
/
16
- 18 8
15 45-046 Engine Plate 1
16 HB-516-18-175 Hex Bolt,
5
/
16
-18 x 1
3
/
4
4
HNFL-516-18 Flange Lock Nut,
5
/
16
- 18 4
17 45-373 Pump 1
18 17-151 Cable 1
17-624 Conduit 1
19 45-161 Clamp 1
20 45-162 Tail Pipe 1
21 42-601 Heat Shield 1
HB-716-14-100 Hex Bolt,
7
/
16
- 14 x 1 4
HWL-716 Lock Washer,
7
/
16
4
   󰀪 
18-222 Hose Clamp 2
23 45-111 Throttle Adapter 1
21-161 Wire Block 1
24 45-077 Cable Bracket 1
25 43-024 Engine B&S 18HP 1
18-462 Drain Valve 1
26 18-214 45° Elbow 1
