Accessories
45-016 LIGHT KIT PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 17-537 Square U-bolt 2
2 45-081 Light Bar 1
3 34-201 Light 3
4 45-004 Roll Bar Kit 1
5 43-505 Light Wire Harness 1
INSTALLATION INSTRUCTIONS
45-004-K ROPs Kit is required for Light Kit on all Sand Star Machines�
1� Mount lights to light bar� Outside two facing forwards and center light facing to the rear�
2� Using the square u-bolts, mount light bar assembly to the roll bar�
3� Tighten u-bolts down and make sure light bar and lights are secure�
4� Tighten all hardware�
5� Center toggle switch is wired for lights via the main machine wire harness� The plug for the light wire
harness is zip tied to the left rear post (Ref 5)� Hook light wire harness from lights to the plug on the left
rear post�
6� Use the tie straps provided to secure the light wire harness to the roll bar and the light bar�
7� Test lights�-45-
6� Attach hose sleeve (Ref 9) to rubber elbow with another hose clamp (Ref 3)�
8� Tighten all hose clamps�
