A-3
Front Attachment
13-765 SINGLE BANK HYDRAULIC VALVE PARTS LIST
REF # PART # DESCRIPTION QUANTITY
1* Actuator Housing Assembly 1
2* 13-731-02 Valve Plug 1
3*† 78-415-03 O-Ring Seal 2
4*† 78-415-05 Spacer 3
5* 78-415-04 Flanged Washer HDM10 3
6* 13-731-03 Spool 1
7* 78-415-11 Positioner 1
8* 78-415-08 Plug 3
9* 78-415-09 Lever Group HDS11 3
10* 78-415-10 Metric Socket Screw, M5 x �8 x 45 2
11* 13-731-04 1/4" Ball 1
12*† 13-731-05 Check Valve 1
13 18-341 45° Elbow 4
14 78-417 Straight Handle 1
78-417-01 Tapered Knob 1
* 13-765 Single Bank Hydraulic Valve (includes all * items)
