A-5
Front Attachment
45-005 HYDRAULIC SAND PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 45-126 Ram Mount 1
2 HCP-58-150 Clevis Pin,
5
/
8
x 1
1
/
2
1
3 HHP-18 Bridge Pin,
1
/
8
4
4 13-406 Hydraulic Cylinder 1
5 18-168 45° Elbow 2
6 45-092 Aluminum Sand Plow Blade 1
45-321 Steel Sand Plow Blade 1
7 18-154 Rod End 1
HNJ-58-18 Jam Nut,
5
/
8
- 18 1
8 HB-38-16-100 Hex Bolt,
3
/
8
- 16 x 1 4
HNFL-38-16 Flange Whiz-Loc Nut,
3
/
8
- 16 4
9 13-167 Wear Blade 1
10 HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
2
HW-38 Flat Washer,
3
/
8
2
HWL-38 Lock Washer,
3
/
8
2
HN-38-16 Hex Nut,
3
/
8
- 16 2
11 HB-12-13-300 Hex Bolt,
1
/
2
- 13 x 3 2
HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 2
12 HB-38-16-250 Hex Bolt,
3
/
8
- 16 x 2
1
/
2
2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
13 HCP-12-150 Clevis Pin,
1
/
2
x 1
1
/
2
2
14 45-100 Right Pusher Bar 1
15 45-125 Plow Crossbar 1
16 HCP-58-175 Clevis Pin,
5
/
8
x 1
3
/
4
1
17 45-101 Left Pusher Bar 1
18 18-341 45° Elbow 4
19 45-127 Valve Mount 1
20 HB-14-20-200 Hex Bolt,
1
/
4
- 20 x 2 2
HNFL-14-20 Flange Whiz-Lock Nut,
1
/
4
- 20 2
21 78-417 Straight Handle 1
22 13-765 Single Bank Hydraulic Valve 1
23 45-130 Hose, 51½" 1
24 45-129 Hose, 43" 1
25 2-Bank Valve (on machine)
26 45-068 Hose (on machine to pump)
27 45-128 Hose, 26" 1
28 45-364 Vavle Brace 1
ENGINE MUST BE COOL BEFORE DISCONNECTING THE HOSES�
1� Assemble pusher bars (Ref# 14 and 17) to plow blade (Ref# 6) using one
3
/
8
-16 x 1
1
/
4
bolt (Ref# 10)
and one
3
/
8
-16 x 3 bolt (Ref#11) per pusher bar� There are 2 holes to bolt (Ref# 10) hardware in� Using
hole closest to the blade will result in a shallow cut, whereas using the hole furthest from the
blade will result in a deeper cut
2� Assemble the plow cross tube (Ref# 15) to the front pusher bars (Ref# 14 and 17) using
3
/
8
- 16 x 2
1
/
2
bolts and lock nuts (Ref# 12)�
3� Assemble the ram mount (Ref# 1) to the main frame using the two studs that are welded to the frame
and below the front of the console� Install rod end (Ref# 7) onto cylinder with
5
/
8
jam nut�
4� Using a
5
/
8
x 1
3
/
4
clevis pin (Ref# 16) and
1
/
8
" bridge pin (Ref#3) mount the hydraulic cylinder (Ref# 4) to
the plow crossbar (Ref# 15)� Connect the other end of the hydraulic cylinder to the ram mount (Ref# 1)
using
5
/
8
x 1½ Clevis Pin (Ref# 2) and
1
/
8
" bridge pin (Ref#3)�
5� Slide the plow/pusher bar assembly under machine and connect to machine� Secure using ½ x 1½
clevis pins (Ref# 13) and
1
/
8
" bridge pins (Ref# 3)�
