A-9
Front Attachment
45-009 ALUMINUM 40" SAND PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 45-106 Lift Assembly 1
18-221 Flange Bushing 2
2 HCP-12-150 Clevis Pin,
1
/
2
x 1
1
/
2
2
HHP-18 Bridge Pin,
1
/
8
2
3 45-101 Left Pusher Bar 1
4 HB-38-16-250 Hex Bolt,
3
/
8
- 16 x 2
1
/
2
2
HW-38 Flat Washer,
3
/
8
4
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
5 27-073 Lift Rod 2
6 HB-12-13-200 Hex Bolt,
1
/
2
- 13 x 2 2
HMB-12-14 Machine Bushing,
1
/
2
x 14GA 8
HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 2
7 80-006 Rod End 4
HNJ-12-20 Jam Nut,
1
/
2
- 20 4
8 45-092 Aluminum Sand Plow Blade 1
9 HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
2
HW-38 Flat Washer,
3
/
8
2
HWL-38 Lock Washer,
3
/
8
2
HN-38-16 Hex Nut,
3
/
8
- 16 2
10 HB-12-13-300 Bolt ,
1
/
2
- 13 x 3 2
HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 2
11 HB-38-16-100 Hex Bolt,
3
/
8
- 16 x 1 4
HNFL-38-16 Flange Whiz-Loc Nut,
3
/
8
- 16 4
12 13-167 Wear Blade 1
13 45-100 Right Pusher Bar 1
14 HB-12-13-200 Hex Bolt,
1
/
2
- 13 x 2 2
HMB-12-14 Machine Bushing,
1
/
2
x 14GA 2
HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 2
15 27-073-02 Plow Link, 3" 1
16 45-097 Plow Handle 1
17 15-019 Grip 1
18 HMB-34-14 Machine Bushing,
3
/
4
- 14GA 1
19 HP-18-150 Cotter Pin,
1
/
8
x 1
1
/
2
1
SAND PLOW INSTALLATION
1� Assemble (Ref# 3 and 13) Pusher Bars to (Ref# 8) Plow using (Ref# 9 and 10) hardware� There are 2 holes to bolt
(Ref# 9) hardware in� Using hole closest to the blade will result in a shallow cut, whereas using the hole furthest
2� Assemble the (Ref# 1) Lift Assembly to the Main Frame using the two studs that are under the frame and below the
front of the console�
3� Attach the (Ref# 6) Lift Handle to the lift assembly using (Ref# 18 & 19) Cotter Pin and Machine Bushing� Using
(Ref# 15 & 7) Rod and Yoke attach the handle to the lift assembly�
Arms with Ball Joints to the outside� Bolt from outside with the
1
/
2
" Machine Bushing between Rod End and Lift Arm
and the
1
/
2
- 13 nut on the inside� Use (Ref# 6) Hardware�
5� Slide Plow under machine and connect to machine� Use (Ref# 2) Clevis Pin and Bridge Pin�
6� Lift up the plow using the bottom hole in the Lift Rod as a starting point� Secure to the Pusher Bars� Use (Ref# 4)
hardware� For maximum blade clearance use the second hole from the front of the pusher bar� The three holes in
the lift rods are for adjusting the hand lever� The top hole moves the lever forward� Each hole down moves the lever
to the rear of the machine�
increase down pressure� Twisting the rod end onto the rod will decrease down pressure�
