B-27
Center Attachment
45-011 INFIELD SCARIFIER WITH CHISEL BLADES PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 HHP-18 Bridge Pin,
1
/
8
3
2 HCP-12-200 Clevis Pin,
1
/
2
x 2 2
3 42-205 Left Castor Wheel Bracket 1
10-025 Flange Bushing (Part of 42-205) 2
HG-14-28-180 Grease Fitting,
1
/
4
- 28 x 180° (Part of 42-205) 1
4 HB-38-16-100 Hex Bolt,
3
/
8
- 16 x 1 4
HW-38 Flat Washer,
3
/
8
4
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 4
5 45-116 Center Lift Bar 1
6 13-114 Digger Blades 9
7 42-204 Castor Fork 2
8 HB-12-13-600 Hex Bolt,
1
/
2
-13 x 6 2
9 33-338 Axle Bearing 2
10 42-202 Tire and Wheel 2
11 HNTL-12-13 Nylon Lock Nut,
1
/
2
- 13 2
12 HCP-58-250 Clevis Pin,
5
/
8
x 2
1
/
2
1
13 HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
5
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 5
14 HMB-34-14 Machine Bushing,
3
/
4
x 14GA 2
15 42-206 Right Castor Wheel Bracket 1
10-025 Flange Bushing (Part of 42-206) 2
HG-14-28-180 Grease Fitting,
1
/
4
- 28 x 180° (Part of 42-206) 1
16 42-215 Short Spacer 2
17 HMB-34-10 Machine Bushing,
3
/
4
x 10GA 8
18 42-214 Long Spacer 2
19 42-539 Lynch Pin,
5
/
16
2
20 HB-38-16-150 Hex Bolt,
3
/
8
- 16 x 1
1
/
2
2
HW-38 Flat Washer,
3
/
8
2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
21 HB-38-16-125 Hex Bolt,
3
/
8
- 16 x 1
1
/
4
2
HW-38 Flat Washer,
3
/
8
2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
INSTALLATION INSTRUCTIONS
1� Assemble seven digger blades (Ref 6) to the center lift bar (Ref 5) using the
3
/
8
- 16 x 1
1
/
4
bolts, wash-
ers and nuts (Ref 21) on the outside slots and
3
/
8
- 16 x 1 bolts and nuts (Ref 13) on the holes� Do not
put the two digger blades on that mount with the caster arm hardware (Ref 20)�
2� Mount the right and left caster wheel brackets (Ref 3 and 15) to the center lift bar (Ref 5) using
3
/
8
- 16 x 1 bolts, washers and nuts (Ref 4)� Mount the last two digger blades at this time using the
3
/
8
-
16 x 1
1
/
2
bolts, washers and nuts (Ref 20)�
5� Extend hydraulic cylinder all the way down by pushing the lever forward�
6� Mount the rod end of the cylinder onto the center lift bar and secure with a clevis pin (Ref 12) and
bridge pin (Ref 1)�
7� Attach the arms on the center lift bar to the main frame on the machine and secure with clevis pin (Ref
2) and bridge pin (Ref 1)�
8� Turn machine on and test for proper operation�
9� Adjust castor wheels (Ref 12) by placing the short (Ref 16) or long spacer (Ref 18) on the castor wheel
fork before placing the castor wheel assembly into the castor wheel brackets� Be sure both castor
wheels are adjusted to the same height�
