C-41
Rear Attachment
42-392Q 84"(213CM) ProBrush TOURNAMENT RAKE PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-489 Tip Guard 2
2 42-397 Outside Brush Arm, LH 1
3 HSTP-516-18-100 Phillip Truss Head Screw,
5
/
16
- 18 x 1 16
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 16
4 11-055 Compression Spring 4
5 HB-38-16-250 Hex Bolt,
3
/
8
- 16 x 2
1
/
2
2
HW-38 Flat Washer,
3
/
8
2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
6 42-396 Outside Brush Arm Mount 2
7 HSTP-516-18-100 Phillips Truss Head Screw,
5
/
16
- 18 x 1 4
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 4
8 HSTP-516-18-125 Phillips Truss Head Screw,
5
/
16
- 18 x 1¼12
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 12
9 42-102 84" Outside Rake 3
10 HMB-58-14 Machine Bushing,
5
/
8
x 14GA 4
11 HRP-14-100 Roll Pin,
1
/
4
x 1 2
12 43-144 84" Draw Bar 1
13 50-081 Rubber Bumper 4
HNFL-38-16 Flange Lock Nut,
3
/
8
- 16 6
15 42-399 Brush Arm Mount, LH 1
16 HB-38-16-250 Hex Bolt,
3
/
8
- 16 x 2½ 2
HNTL-38-16 Nylon Lock Nut,
3
/
8
- 16 2
17 42-454 Inside Brush Arm, LH 1
18 42-122 Rake Spring 12
42-177 Spring Holder 12
19 HSTP-516-18-075 Phillip Truss Head Screw,
5
/
16
- 18 x
3
/
4
6
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 6
20 42-129 Groomer Blades 3
21 42-393 Outside Brush Arm, RH 1
22 42-105 Top Strap 4
23 42-107 Matting 4
24 42-106 Bottom Strap 4
25 42-135 Finishing Blades 4
26 42-466 Brush, 21" 4
27 42-465 Brush Clamp 4
28 HB-516-18-125 Hex Bolt,
5
/
16
- 18 x 1¼ 12
HNFL-516-18 Flange Whiz-Loc Nut,
5
/
16
- 18 12
29 42-453 Inside Brush Arm, RH 1
30 42-398 Brush Arm Mount, RH 1
31 HB-14-20-175 Hex Bolt, ¼ - 20 x 1
3
/
4
1
HNTL-14-20 Nylon Lock Nut, ¼ - 20 1
