Smiths Medical CADD-Solis User Manual

47
References and Troubleshooting
ContinuousDeliveryRechargeableBatteryPack
Lifewithscreenintensitysetto3
Rate Life Volume
0.4 mL/hr 119 hrs 47.6 mL
1 mL/hr 89 hrs 89 mL
5 mL/hr 88 hrs 440 mL
10 mL/hr 86 hrs 860 mL
30 mL/hr 43 hrs 1290 mL
Classification
CF

, Class II

.
Moisture Protection
Splashproof (
) per IEC 60529.
Maximum Infusion Pressure
27.0 psi [1.86 bar].
MaximumTimetoOcclusionAlarm
0.1 mL/hr - medication cassette reservoir:
108minutes. CADD® administration set:
122minutes.
10 mL/hr - medication cassette reservoir:
44seconds. CADD® administration set:
122seconds.
NOTE: Values are nominal and based on
actual test data.
Bolus Volume at Occlusion Alarm
0.1 mL/hr - medication cassette reservoir:
0.107mL. CADD® administration Set: 0.136 mL.
10 mL/hr - medication cassette reservoir:
0.116mL. CADD® administration set: 0.124 mL.
NOTE: Values are nominal and based on
actual test data.
Power Sources
Four AA (IEC LR6) alkaline batteries; AC
adapter; rechargeable battery pack.
Charging System for Internal Memory Backup
Battery
The internal memory backup battery utilizes
lithium manganese dioxide technology. It
charges whenever the pump is powered on and
has a 10month memory capacity once it has
been charged for 250 hours at 20°C (68°F).
SystemOperatingTemperature
2°C to 40°C (36°F to 104°F).
SystemStorageandTransportationTemperature
–20°C to 60°C (–4°F to 140°F).
RelativeHumidity
20% to 90% relative humidity, non-condensing.
Atmospheric Pressure
70 kPa (10.2 psi) to 106 kPa (15.4 psi).
SystemDeliveryAccuracy
± 6% (nominal). At low infusion rates, this
accuracy may not be achieved for short periods.
During the total infusion time, the accuracy
averages out.
WARNING:
• Ensurethatthe±6%systemdeliveryaccuracy
specication is taken into account when
programming the pump and/or lling the
reservoir.Failuretodosomayresultin
medicationinthereservoirbecomingdepleted
sooner than expected. If the pump is being used
todelivercriticalorlifesustainingmedication,
theinterruptioninthedeliveryofmedication
could result in patient injury or death.
• Systemdeliveryinaccuraciesmayoccuras
a result of back pressure or uid resistance,
whichdependsupondrugviscosity,catheter
size, and extension set tubing (for example,
microbore tubing), and placing the infusion
reservoirand/orpumpaboveorbelowthelevel
ofthepatient.Systemdeliveryinaccuracymay
resultinunderorover-deliveryofmedication,
which could result in death or serious injury to
the patient.
System Definition
CADD
®
-Solis pump with:
• An attached medication cassette reservoir
and CADD
®
extension set or
• an attached CADD
®
administration set or
CADD
®
-Solis pump with:
• an attached medication cassette reservoir
with flow stop feature and CADD
®
extension
set or
• A CADD
®
administration set with flow stop
feature.
