5.0 General Welding Information
34
BOC Smootharc 180 Multiprocess operating manual
5.1 Recommended Welding Parameters for MIG/MAG
Argoshield Light
Indicative
WeldingParameters Dip Transfer
Spray
Transfer
Material thickness (mm) 1–1.6 2 3 4 3
Welding position Horizontal /
Vertical
Horizontal /
Vertical
Horizontal /
Vertical
Horizontal /
Vertical
Horizontal
Wire diameter (mm) 0.8–0.9 0.8–0.9 0.8–0.9 0.9–1.0 0.8
Current (amps) 45–80 60–100 80–120 80–150 160–180
Voltage (volts) 14–16 16–17 16–18 16–18 23–25
Wire feed speed (m/min) 3.5–5.0 4.0–7.0 4.0–7.0 4.0–7.0 7.5–9.0
Gas rate ow (L/min) 15 15 15 15 15
Travel speed (mm/min) 350–500 350–500 320–500 280–450 800–1000
Stainshield (Aus) or Stainshield Light (NZ)
Indicative
WeldingParameters Dip Transfer
Material thickness (mm) 4 6 8
Welding position
Horizontal /
Vertical
Horizontal /
Vertical
Horizontal /
Vertical
Wire diameter (mm)
0.9–1.0 0.9–1.0 0.9–1.0
Current (amps)
100–125 120–150 120–150
Voltage (volts)
17–19 18–20 18–20
Wire feed speed (m/min)
5.0–6.5 6.0–7.5 6.0–8.0
Gas rate ow (L/min)
15 15 18
Travel speed (mm/min)
400–600 280–500 280–450
