Copyright 12/14 101 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
SCREEN HOIST COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 977-200426 Screen Hoist Pole Assembly
2. 900-4904-90 3/4” Spring Latch
3. 977-200425 Screen Hoist Pivot Head Assembly
4 a. 900-3920-77 Screen Hoist Cylinder
b. 901-100031 Flow Restictor Only (Not Shown)
5. 900-4901-83 1/2” Spring Latch
6 a. 977-200423 Screen Hoist Long Arm Assembly
b. 900-1911-59 Split Steel Bushing
7 a. 977-200424 Screen Hoist Long Arm Assembly
b. 900-1911-59 Split Steel Bushing
8. 977-302391 Screen Hoist Pole Support
9. 977-302388 Screen Hoist Pole Support
10. 901-100032 Chain Assembly With Slip Hook (Not Shown)
11. 900-9905-86 Forged Grab Hook (Not Shown)
12. 977-302398 Electric Pump & Reservoir Cover (Not Shown)
13. 900-6907-66 Disconnect Switch
14 a. 900-9905-85 Electric Pump With Controller & Reservoir (Not Shown)
b. 900-2915-56 Electric Motor Only (Not Shown)
c. 900-2915-57 Controller Only (Not Shown)
d. 900-2915-58 Controller Cord Only (Not Shown)
16. 977-100158 Screen Hoist Assembly (Includes 1-14a)
SCREEN HOIST COMPONENTS
