Copyright 12/14 32 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
EQUIPMENT SPECIFICATIONS
The Smoracy, LLC Recycler machine is designed to reduce wood and all organic products into mulch.
The unit is powered by one of several optional engines. Power is transmitted through a V-Belt system
to the cutter head. Applicable service manuals should be consulted concerning power units and clutches
for proper maintenance. Any available manuals pertaining to these component parts are also shipped
with the unit. Additional copies can be purchased through their respective manufacturers.
FRAME: Made from 20” (508 mm) deep formed section steel plate, with 18” (457 mm) deep
formed section cross-bracing.
AXLES: (2 Axle) 15,000 lb. (6804 kg) tandem axles with single wheels and leaf springs, air brakes.
(3 Axle) 25,000 lb. (11,340 kg) tri-axle with single wheels and leaf springs, air brakes.
TIRES: (2 Axle) Four (4) 315/80R22.5(L).
(3 Axle) Six (6) 385/65R22.5
STABILIZERS: Two (2), hydraulically adjustable for height.
TONGUE: 3” (76.2 mm) pintle ring hitch. 1/2” (12.7 mm) safety chains with hooks. Fifth Wheel
option available.
HYDRAULIC 140 gallon (530 liter) capacity with in-tank element filter on return line, strainer
TANK: on tank inlet, baffle, sight gauge, shut-off valves, and oil temperature gauge,
rubber mounted.
BRAKES: Air brakes.
FUEL TANK: 500 gallon (1892 liter) with sight gauge, lockable cap and shock mounted.
SPECIFICATIONS - FOR MODEL 3680 BEAST
EQUIPMENT SPECIFICATIONS
AIR TANK: Equipped with a gasoline engine operated air compressor, hose and impact wrench
for changing cuttermill tools.
