SMORACY BEAST 3680 - ELECTRICAL SECTION; Electrical Schematics and Systems

Copyright 12/14 84 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
Brown
White White
White White
Black Black
BlackBlack
Brown
Red
White
Brown
Red
White
Brown
~
~
Hitch
White
White
Yellow
~
~
~
Green
~
Socket
1
2
3
4
5
7
6
Black - Clearance
White - Ground
Green - Right Turn
Red - Stop
Brown - Tail Light
Yellow - Left Turn
~~~
~
~
Clearance Clearance
Clearance Clearance
Clearance
Tail Light
Right Turn
Tail Light
Left Turn
RECYCLER EMERGENCY HYDRAULIC SHUT DOWN
With Caterpillar Engine
ELECTRICAL SECTION
RECYCLER TAIL LIGHT CIRCUIT
NOTE:
Wiring diagram for the control
panel box and autofeed is supplied
with your manual package.
ITEM PART NUMBER DESCRIPTION
1. 977-100018 Hydraulic Shut Down Assy.
2. 900-2902-92 Electrical Junction Box
3. 900-3921-77 24 Volt Coil
900-3918-63 Wiring Harness for 24 Volt Coil
A. 900-3910-31 Dump Valve Block (1 Speed)
B. 900-3921-72 Dump Valve Block (3 Port, optional)
C. 900-3920-39 Dump Valve Block (4 Port, optional)
