SMORACY BEAST 3680 - Base Component Parts List

Copyright 12/14 89 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
LOCATION PART NUMBER DESCRIPTION
1. 977-200202 Storage Cabinet
2. 977-200281 Engine Adjuster Assembly
3. 977-100009 140 Gallon Hydraulic Tank (see hydraulic tank components)
4. 977-100033 Cat Walk Assembly
5. 900-2906-56 Winch
6. 977-301158 Belt Conveyor Cover Guide
7. 977-200156 Replaceable Roll Top
8. 977-100028 Cabinet Door Closer Assembly
9. 977-301385 Rear Cabinet Door
10. 977-301386 Front Cabinet Door
11. 900-4908-19 Cabinet Latch
12. 977-300277 Belt Shield Door
13. 977-200280 Engine Adjuster Assembly
14. 977-200155 Yoke Pivot Pin Assembly
15. 977-301701 Anvil Access Door
16. *-* Engine Sheave Bushing
17. *-* Cutterhead Sheave Bushing
18. *-* Engine Sheave
19. *-* Cutterhead Sheave
20. *-* Drive Belt
21 a. *-* Cutterhead Bearing - Clutch Side
b. *-* Cutterhead Bearing - Radiator Side
22. 977-200154 Base Side Cover Plate
23. *-* Cuttehead Assembly (less teeth) 6” Shaft
24. 977-200154 Base Side Cover Plate
25. 977-301887 Rubber Flap
26. 977-300469 Rubber Flap Bolt Plate
27. 977-301605 Yoke Lock Cover
28. 900-3927-27 Yoke Lift Cylinder
29. 977-200200 Yoke Lock Pin Assembly
30. 977-200199 Yoke Lock Base Assembly
31. 900-3927-26 Yoke Lock Cylinder
BASE COMPONENTS
