Copyright 12/14 45 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 TRANSPORTATION PROCEDURES
WARNING
1) Clean out any existing material in the Recycler by
allowing the machine to operate for several minutes
without further loading.
2) From the remote control stop the InfeedConveyor
Chain and the Feedwheel rotation.
3) Idle engine and disengage clutch.
4) Place the Auger manual control valve handle in the
off or middle position to stop the Augers from
operating.
5) Place the Discharge Belt Conveyor manual control
handle in the off or middle position to stop the
Discharge Belt Conveyor from operating.
6) Make sure the Feedwheel is in the lowered position.
7) On the engine gauge panel turn the throttle control
switch to the idle position and move switch from
remote control to manual.
8) Disengage clutch, turn off engine, wait for the
Cutterhead to come to a complete stop, turn Battery
Disconnect Switch off, and you must have the
ignition key in
YOUR possession.
9) Disconnect and stow tether remote control in the
tool box.
10) Radio remote control can be stored inside control
cabinet on the left side or road side of the Recycler.
11) Remove all potential fire hazards. Remove hazards
such as wood debris, fuel, oil, etc. The top of the
engine, around the exhaust system and turbo are
areas to be kept especially clean. Clean beside and
around the engine, around and under fuel and
hydraulic tank, inside belt shield, inside control
cabinets and anywhere else materials have collected.
This must be done prior to starting the machine each
day, must be done every time the machine is left
unattended during the day, and definitely must be
done at the end of each day. Spend some time
walking around the machine checking for any hot
spots. Check Cutterhead, Infeed, and Discharge
Belt Conveyor bearings to make sure they are not
hot so they do not start a fire. It is your responsibility
to prevent fires so keep the machine and area around
clean from debris.
12) Restart engine and fold the Discharge Belt Conveyor
to transport position. Make sure to follow the proper
folding procedures.
13) Make sure all manual hydraulic control valve are in
the off or middle positions.
TRANSPORTING THE RECYCLER
14) Raise the front of the machine with the front
stabilizer and remove the blocks from under the
frame.
15) Couple recycler to transport vehicle by lowering the
machine onto the pintle hitch (if equipped). Then close
hitch and lock it.
16) Once again disengage clutch, turn off engine, wait
for the Cutterhead to come to a complete stop, turn
Battery Disconnect Switch off, and you must have
the ignition key in
YOUR possession.
17) Attach the safety chains by crossing them under hitch,
make sure to allow the proper amount of slack in
chains to avoid binding when making turns.
18) Connect the air brake lines and plug in the electrical
connection for the lights on the machine.
19) Check running, lights, turn signals, and brake lights.
All must be operating properly before transporting
the machine.
20) Lock control cabinet doors.
21) Pull pin on the clutch handle and fold up out of the
way.
22) Lock radiator debris screen in the transport position.
23) Fold and secure swing ladder on the right side or
curb side of the machine.
24) Check tires for low pressure, cuts or damaged rims.
25) Inspect and replace any axle dust caps that are
damaged or leaking.
26) Check oil level in hubs and grease axles per axle
manufactures manual.
27) Inspect and adjust brakes as needed per axle
manufactures manual.
28) Walk around Recycler to confirm that everything is
secure and that there isn’t anything loose that could
fall off the machine while transporting. Look under
Recycler to ensure nothing is dragging. Look down
both sides of the Recycler checking for anything
sticking out that may become damaged during
transporting.
29) The Recycler is now ready for transport. Make sure
to obey all local regulations and laws regarding
transporting a machine of this size.
BEFORE TRANSPORTING THE MACHINE THE FOLLOWING MUST BE COMPLETED
