MODEL 3680
BASIC LOCATION OF CONTROLS FOR TYPICAL 3 AXLE MACHINE
1. Infeed Conveyor Control
2. Feedwheel Rotation Control Valve
3. Yoke Control Valve
4. Concave Door Control Valve
5. Discharge Belt Conveyor Control Valve
6. Auger Control Valve
7. Discharge Belt Conveyor Fold Control Valve
8. Discharge Belt Conveyor Fold Control Valve
9. Stabilizer Control Valve
10. Yoke Lock Bars Control Valve
11. Digital Autofeed/Tach
12. Powerview Gauge
13. Module Controls
14. Ignition Switch
15. Radio/Tether or Manual Control Switch
16. Radio or Tether Switch
17. Throttle Control (Increase/Decrease)
18. Throttle Control (Idle/Run)
CONTROLS
CONTROLS/START UP PROCEDURES
1. 2. 3. 4.
10.
9.
8.
7.
6.
5.
12.
13.
11 .
14.16.
17.15. 18.
