Copyright 12/14 109 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
AUGER COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 900-1909-01 Auger Bearing
2. 900-1905-25 Auger Sprocket
3. 900-1904-85 Bushing
4. 900-3924-31 Auger Hydraulic Motor
5. 900-4902-75 Auger Motor Mount Adjuster
6. 977-200991 Auger Motor Mount Adjuster Plate
7. 900-1905-27 Bushing
8. 900-1905-26 Sprocket
9. 977-200990 Auger Clean Out Door
10. 977-200860 Auger Stub Shaft - Flange Style
11. 900-4918-08 Stud for Flange Style Auger
12 a. 977-200862 Left Hand Auger Assembly - Flange Style
b. 977-200904 Left Hand Wearmax Auger Ass’y - Flange Style (for Shingles)
13 a. 977-200861 Right Hand Auger Assembly - Flange Style
b. 977-200905 Right Hand Wearmax Auger Ass’y - Flange Style (for Shingles)
14. 900-1905-22 Idler Sprocket With Bearing
15 a. 901-100006 Auger Chain Kit - 15’ (Not Shown)
b. 900-1908-29 Roller Chain Half Link (Not Shown)
c. 900-1908-28 Roller Chain Master Link (Not Shown)
16. 901-100030 Auger Motor Chain (Not Shown)
To Next Page
