SMORACY BEAST 3680 - Infeed Conveyor Parts List

Copyright 12/14 87 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
LOCATION PART NUMBER DESCRIPTION
1. 977-100036 Tail Shaft Assembly
2. 977-100038 Infeed Tail Shaft Adjustment Assembly (includes a.,b.)
a. 977-100049 Infeed Tailshaft Take Up Screw Weldment
b. 977-200231 Infeed Tailshaft Take Up Bearing Pad Weldment
3. 900-1906-33 Tail Shaft Bearing
4. a. 977-100147 Complete Chain Assembly
b. 977-100146 Single Chain Link Assembly
c. 900-4904-51 Set Screw
d. 977-300534 Pin
e. 977-300532 Slat Bushing
5. 977-100018 Hydraulic Shutdown Assembly
(See Emergency Hydraulic Shutdown diagram for list of parts
in Electrical Section)
6. *-* Infeed Conveyor Hydraulic Motor
7. 977-300459 Hydraulic Motor Mount
8. 900-1905-21 Bushed Sprocket For Infeed Conveyor
9. 900-1903-43 Bushing
10. 977-200196 Infeed Conveyor Chain Guard
11. 900-1900-08 Bushing
12. 900-1907-65 Bushed Sprocket
13. 977-300233 Rear Infeed Drive Filler
14. 901-100010 Infeed Conveyor Drive Chain Kit -5’
a. 900-1910-15 Roller Chain Half Link (not shown)
b. 900-1910-16 Roller Chain Master Link (not shown)
15. 977-100039 Infeed Head Shaft Adjusting Assembly
a. 977-100052 Infeed Head Shaft Bearing Adjustment Bolt
b. 977-301031 Infeed Head Shaft Adjustment Block
c. 977-200267 Infeed Head Shaft Bearing Pad
16. 977-100035 Infeed Head Shaft Weldment
17 a. 977-301013 Wing, Roadside
b. 977-301014 Wing, Curbside
18. *-* Gear Box
19. 977-000224 Infeed Tail Shaft Guard
20. 900-4908-55 Hydraulic Motor Adjuster Eyebolt
21. 977-100308 Copmplete Infeed Assembly
INFEED CONVEYOR COMPONENTS
