SMORACY BEAST 3680 - Hydraulic Pressure Settings and Procedures

Copyright 12/14 79 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 HYDRAULIC SECTION
APPROXIMATE PUMP FLOW INFORMATION FOR REFERENCE ONLY
(Will vary depending on engine options and pump efficiency)
HYDRAULIC SECTION
HYDRAULIC RELIEF PRESSURE SETTINGS
DESCRIPTION SINGLE SPEED THREE SPEED
Infeed Conveyor 1200 PSI (83 bar) 1800 PSI (124 bar)
Internal Drive Feedwheel 1500 PSI (103 bar) 1500 PSI (103 bar)
Augers 2100 PSI (145 bar) 1800 PSI (124 bar)
Yoke Cylinders 2500 PSI (172 bar) 1500 PSI (103 bar)
Discharge Conveyor 1800 PSI (124 bar) 1800 PSI (124 bar)
Discharge Conveyor Fold 1800 PSI (124 bar) 1800 PSI (124 bar)
Concave Door: “A” Port 600 PSI (41 bar) 600 PSI (41 bar)
“B” Port 1200 PSI (83 bar) 1200 PSI (83 bar)
Stabilizer 1800 PSI (124 bar) 1800 PSI (124 bar)
CAUTION
DO NOT UNDER ANY CIRCUMSTANCES OVER-SET THESE PRESSURES, BECAUSE IT WILL
CAUSE DAMAGE TO COMPONENT PARTS AS WELL AS HYDRAULIC PARTS.
CONSTANT SPEED DISCHARGE CONVEYOR (if equipped)
Compensator 2600 PSI (179 bar)
High Speed 2000 PSI @ 18 GPM (138 bar @ 68.1 LPM)
Low Speed 2000 PSI @ 6.5 GPM (138 bar @ 24.6 LPM)
It is highly recommended that after initial start-up of the recycler and after any replacement of
hydraulic components, that fittings and hoses be re-checked for leaks and clearances.
