Copyright 12/14 78 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 TROUBLE SHOOTING
TROUBLE SHOOTING GUIDE
PROBLEM - NONE OF THE RADIO REMOTE CONTROLS ARE WORKING:
(Functions are working)
Possible Cause Possible Solutions
Also refer to: None of the hydraulic systems are working.
Switches in gauge panel in wrong position. Check switches to make sure they are positioned
correctly.
Switch on remote not ON. Check to make sure switch in remote is ON.
Battery inside Radio Remote is dead. Replace battery.
Tripped circuit breaker or blown fuse. This electrical circuit is protected by either a circuit
breaker in the face of the gauge panel or a bar fuse
located in a fuse holder on the side. Reset the circuit
breaker or replace the bar fuse as necessary.
No radio signal. Too far away from machine. Also check antenna and
coaxial cable connections.
Radio Remote damaged from being Connect the Tether Remote to the machine and if
dropped or left in the weather. everything works fine than the Radio Remote is to
blame.
No pilot pressure to electric solenoid valves. The recycler is equipped with electric solenoid
controlled valves to be able to control certain functions
from the remote control. These valves are controlled
by the solenoids but shifted by pilot pressure from the
hydraulic system. The pilot pressure is picked up from
the hydraulic circuit that supplies oil to the Feedwheel
Yoke up and down. If there is not pressure in that
system than there is not any pilot pressure to shift any
of the electric valves. Refer to the Feedwheel Yoke
will not raise using the manual control.
