SMORACY BEAST 3680 - HYDRAULIC SECTION

Copyright 12/14 77 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 TROUBLE SHOOTING
TROUBLE SHOOTING GUIDE
PROBLEM - CONCAVE DOOR WILL NOT MOVE USING THE RADIO OR TETHER CONTROLS:
(All other functions are working)
Possible Cause Possible Solutions
No electrical signal to the solenoid Check for electrical power at the solenoid while
on the control valve. engaging the switch on the remote used to operate
the Feedwheel. If you have electrical power at the
solenoid on the control valve then that means that the
solenoid is faulty. If there isn’t any electrical power
than you will need to refer to the electrical schematic
supplied with the machine to trace the problem. Could
be a broken wire or a faulty relay inside the engine
control panel.
Faulty switch in Remote Control. If using the Radio Remote, Switch to the Tether
Remote and vice versa to determine if the problem
may be in the remote.
PROBLEM - NONE OF THE TETHER REMOTE CONTROLS ARE WORKING:
Possible Cause Possible Solutions
Also refer to: None of the hydraulic systems are working.
Switches in gauge panel in wrong position. Check switches to make sure they are positioned
correctly.
Poor connection at Deutsch plug. Check connection to make sure it is secure.
Tripped circuit breaker or blown fuse. This electrical circuit is protected by either a circuit
breaker in the face of the gauge panel or a bar fuse
located in a fuse holder on the side. Reset the circuit
breaker or replace the bar fuse as necessary.
Tether Remote Control cable damaged. Inspect cable for any cut or damaged wire. Try using
the Radio Remote Control and if everything works than
the problem lies with the Cable Remote Control.
No pilot pressure to electric solenoid valves. The recycler is equipped with electric solenoid
controlled valves to be able to control certain functions
from the remote control. These valves are controlled
by the solenoids but shifted by pilot pressure from the
hydraulic system. The pilot pressure is picked up from
the hydraulic circuit that supplies oil to the Feedwheel
Yoke up and down. If there is no pressure in that
system than there is not any pilot pressure to shift any
of the electric valves. Refer to the Feedwheel Yoke
will not raise using the manual control.
