SMORACY BEAST 3680 - Page 85

Copyright 12/14 83 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
BOLT TORQUE CHARTS
(THESE TORQUES ARE BASED ON DRY, CLEAN THREADS)
DESCRIPTION BOLT SIZE FT.-LBS. TORQUE Nm TORQUE
Cutter Body Holders Bolts 1”-14 TPI 700 949
Tooth Inserts 7/8”-14 TPI 500 678
Raker Wear Pad Bolts 3/4”-10 TPI 346 510
Cutter Head Shaft Bearing Bolts 1”-8 TPI 900 1220
Cutter Head Bearing Cap Bolts 1”-8 TPI 375 (approx.) 508 (approx.)
Infeed Conveyor, Head Shaft Bolts 3/4”-10 TPI 376 510
Screen Mount Bolts 3/4”-10 TPI 376 510
Discharge Conveyor Brg. Bolts 5/8”-11 TPI 160 217
Engine Hold Down Bolts 3/4”-10 TPI 376 510
Infeed Tail Shaft and Feedwheel Brg. Bolts 3/4”-10 TPI 376 510
Engine Sheave Bushing Bolts 3/4”-10 TPI 376 510
Cutterhead Sheave Bushing Bolts 1 1/8”-7 TPI 600 813
LUBRICATION/ BOLT TORQUE
KEEP LUG NUTS PROPERLY TIGHTENED, CHECK NEW UNIT BEFORE OPERATION, CHECK AGAIN
AFTER 20-25 MILES (32-40 km) AND REGULARLY CHECK AT LEAST WEEKLY.
10 Lug Hubs (3/4” - 16 Studs) ....................................................450 - 500 ft.-lb. Torque (610 - 678 Nm)
(Torques per axle manufacturer specifications)
Before tightening bolts be sure you have the correct size bolt for the correct amount of torque.
Use only factory approved cutterhead components.
LUBRICATION
Then fully purge again before the machine is put back into operation. Failure to do this will ruin the bearings.
Bearings may corrode when the machine is setting idle.
The second largest cause of bearing failure is operating them at high speeds when the grease is cold. This causes
the bearing race to turn on the shaft. Naturally this ruins the bearing as well as the shaft. Allow the bearings to turn
at slower speeds for at least five minutes. Also check the bearing lock collar set screws for tightness each 30
days. A loose lock collar allows the sleeve to turn on the shaft. Failed bearings diagnosed as contamination or cold
starts at high speed are not covered by warranty or by the bearing manufacturer.
7) Infeed Gear Box
Fill half full (20 oz. or .59 L) with EP 90 petroleum based gear oil. This oil should be changed after the first 50 hours
of operation and every 1000 hours thereafter. Change immediately if oil exceeds 200
0
F (93
0
C).
8) Feedwheel Gear Box
Fill half full (23 oz. or .68 L) with EP 90 petroleum based gear oil. This oil should be changed after the first 50 hours
of operation and every 1000 hours thereafter. Change immediately if oil exceeds 200
0
F (93
0
C).
