SMORACY BEAST 3680 - Page 33

Copyright 12/14 31 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
3” PINTLE RING
DISCHARGE CONVEYOR
HYDRAULIC MOTOR
STABILIZER
FUEL TANK
FILLER CAP
AUGER DRIVE
HYDRAULIC MOTOR
BELTSHIELD
HYDRAULIC
SHUTDOWN SWITCH
HYDRAULIC
SHUTDOWN
SWITCH
MAIN DRIVE CONTROLS
(CONTAINS ALL MANUAL &
ELECTRICAL CONTROLS FOR
OPERATING THE MACHINE)
HYDRAULIC
TANK
AIR PRE-
CLEANER
AIR
CLEANER
EQUIPMENT SPECIFICATIONS
COMPONENT PARTS
MODEL 3680 “ROADSIDE” VIEW
Picture shown is typical, your machine may have other options
