SMORACY BEAST 3680 - Component Parts Diagrams

Copyright 12/14 30 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680
STABILIZER
INFEED CONVEYOR
TAKE-UP BEARING
MAIN
BEARING
INFEED CONVEYOR
YOKE CYLINDER
YOKE
MAINTENANCE
DOOR
HYDRAULIC
SHUTDOWN SWITCH
MAGNETIC HEAD
PULLEY
BATTERY
BOX
DEBRIS
SCREEN
EQUIPMENT SPECIFICATIONS
HYDRAULIC
SHUTDOWN
SWITCH
COMPONENT PARTS
MODEL 3680 “CURBSIDE” VIEW
Picture shown is typical, your machine may have other options
AIR
COMPRESSOR
STORAGE
BOX
