Copyright 12/14 117 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 HYDRAULIC COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 4510326 Bearing Kit, Front
2. 4510327 Swashplate Bearing Kit
3. 4510330 Bearing Kit, Rear
4. 1700050 Dias Spring
5. 1700890 Swashplate
6. 5000569 Servo Piston Seal
7. 5000581 O-Ring
8 a. 1700542 Valve Plate, CW, KRR (SB-2001-023)
b. 1700202 Valve Plate, CW, KRR
c. 1700210 Valve Plate, CCW, KRL
9. 1700257 Check Valve Spring (SB-2001-020)
10. 1700256 Check Valve Spring (SB-2001-020)
11. 1700259 Cylinder Block Kit, 41/45cc
12. 1700551 Cylinder Block
13. 3104095 Washer
14. 3103486 Spring
15. 3103485 Spring Retainer
16. 019026 Retaining Ring
17. 4700091 Slipper Hold Down Pin
18. 3103487 Slipper Retainer Guide
19. 3103488 Slipper Retainer
20. 3104068 Piston Assembly
Constant Speed Pressure Compensated Pump
P/N 900-3923-11 (Housing, Shaft Seal, and Displacement Limiter)
