Copyright 12/14 119 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 HYDRAULIC COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. ** Dust Seal
2. ** Housing Seal
3. ** Metal Backup Shim
4. ** High Pressure Seal
5. ** Metal Backup Shim
6. ** Polyamide Seal
7. ** Shaft Seal
8. ** Rear Housing Seal
9. ** Body Seals (2)
10. ** End Cover Seal
11. ** Seal Carrier
12. ** Thrust Washer
13. 500018252 Front Thrust Bearing
14. 500018003 Front Housing Bearing (1” Wide)
15. 500130823 Housing
16. 500018002 Rear Housing Bearing (1/2” Wide)
17. 500018059 Rear Thrust Bearing
18. 500014008 Drive Link Kit
19. 500015006 Forward Manifold
20. 500018178 Drive Link Spacer
21 500607005 Standard Rotor Kit
22. 500012001 Balance Plate (3 Balls Included)
23. 500018048 Steel Ball
24. 500016001 End Cover
25. ---- Tag
26. 500445045 Bolt Set
27 Long 1 1/4” Shaft
28. 500449102 Key
29. 500449301 Bolt
30. 500449302 Washer
31. 500449201 Wire Ring
32. 500444001 Seal Kit
NOTE: Items 1-12 are included in the seal kits.
AUGER MOTOR
P/N 900-3924-31
