SMORACY BEAST 3680 - Page 143

Copyright 12/14 125 S/N XXXX WO#XXXXXX
Smoracy, LLC
MODEL 3680 HYDRAULIC COMPONENTS
LOCATION PART NUMBER DESCRIPTION
1. 15111 Cap Screw
2. 15106 Shaft Seal
3. 15056 Seal Carrier
4. 15105 Backup Ring
5. 15301 Quad Ring
6. 15133 O-Ring
7. Output Shaft
8. 150152 Thrust Washer
9. 15011 Retaining Washer
10. 15118 Cone
11. 15128 Cup
12 a. 15052 Front Flange
b. 15055 Center Flange
13. 15129 Pipe Plug
14. 15128 Cup
15. 15118 Cone
16. 15163 Keyed Washer
17. 15162 Lock Washer
18. 15138 Lock Nut
19. 15004 Planet Carrier
20. 15003 Internal Gear
21. 15102 O-ring
22. Motor Adapter
23. 15129 Pipe Plug
24. Sun Gear Kit
25. 15110 Bolt
26. 15129 Pipe Plug
27. 15112 Thrust Washer
28. 15115 Planet Bearing
29. 15006 Planet Gear
30. 15008 Planet Pin
31. 15107 Retaining Ring
32. 15102 O-Ring
INFEED CONVEYOR GEAR BOX
P/N 900-3901-54
