MODEL 3680 HYDRAULIC COMPONENTS
PILOT CONTROL
LOCATION PART NUMBER DESCRIPTION
1 900-3915-71 Cartridge, Solenoid Valve
2 7850-001 Housing Actuator
3. 8300-001 Spring
4. 8298-001 Spacer
5 10818-001 Spacer
6. 10819-001 Collar, Spring
7. 8297-001 Screw, Spool
8 8293-001 Spacer
9. 7858-001 Guide, Piston Rod
10. 7028-002 Seal, O-Ring
11. 7854-001 Seal, O-Ring
12. 3191-001 Seal, O-Ring
13. 7700-001 Seal, O-Ring
14. 0563-001 Washer, Lock
15 3731-111 Screw, Socket Head Cap, 1/4-20 x 3.50
16. 7856-001 Piston
17. 7855-001 Ring, Retaining
18. 7857-001 Rod, Piston
19. 3637-001 Plug, SAE 6 (With O-Ring)
20. 7904-001 Plate, Bearing
