SNAP CIRCUITS BRIC: STRUCTURES - Bric Bridge

Project 8 BRIC Bridge
Build the circuit as shown, and turn on the slide switch
(S1). The four LEDs (D8, D9, D11, & D12) and lamp (L4)
light, and the melody IC (U32) plays tunes. The 3D
snaps allow the blue and blink red LEDs to be rotated
to shine in dierent directions. Dim the room lights
for best eects.
You can omit the sound by removing the melody IC
(move the color LED (D8) to where the melody IC was).
