SNAP CIRCUITS BRIC: STRUCTURES - Tri-Level House

13
34
4x
2x
2x
Build the circuit as shown, and turn on the slide switch
(S1). The four LEDs (D8, D9, D11, & D12) and lamp (L4)
light, and the melody IC (U32) plays tunes. The 3D snaps
allow the blue and color2 LEDs to be rotated to shine in
dierent directions. Dim the room lights for best eects.
You can remove the melody IC or re-arrange any of the
lights if desired.
14
Project 13 Tri-Level House
