7
Project 16 Overhead Light
4x
2x
Build the circuit as shown, and turn on the slide
switch (S1). The four LEDs (D8, D9, D11, & D12) and
lamp (L4) light. Dim the room lights for best eects.
You can re-arrange the lights as desired, or replace
one with the melody IC (U32).
38
