Project 14 Elevated Circuit
22x
6x
4x
6x
18x
1ox
1ox
3x
Build the circuit as shown, and turn on
the slide switch (S1). The LEDs (D8 & D9)
light, and the melody IC (U32) plays
tunes. You can replace the LEDs and
melody IC with any of the other lights.
35
