3
Chapter 2 Technical Specifications
Item Description / Specification
Display (LCD)
Size (diagonal): 71mm (2.8 in.)
Resolution: 240 x 320 pixels
Digital Camera Focus: Fixed
Laser
Class II
Output power < 1 mW
Wavelength 655 nm
Thermal Laser
Temperature Measurement Range: Thermal Mode -20 to 538 °C (-4 to
1000 °F), Laser Mode -20 to 982 °C (-4 to 1800 °F)
Color Palettes: 5 options: Iron, Rainbow, Plasma, Grey-Iron, Cool-Hot
Thermal Sensitivity (NETD): < 50mK (millidegrees Kelvin)
IR Image Refresh Rate: < 8 times per second
Accuracy at room temperature (20°C/68°F):
< 0°C (32°F): ±3°C (±6°F)
0°C (32°F) to 982°C (1800°F): ±2°C (±4°F) or ±3% whichever is greater.
Accuracy specifications listed are under battery power. Accuracy will vary if the unit is being
charged.
Spectral Range: is 7.7µm to 20µm
IR Image Detector Type: Thermopile
Effective Distance: 1 to 2.5 ft. (30.48 to 76.2 cm)
Spot Size Ratio: 10:1
LED Spotlight
Low: 7 lumens
Med.: 12 lumens
High: 22 lumens
Image Storage Memory Capacity > 300 image files
Image File Format .jpg
USB Interface 2.0 USB, micro USB
Battery
Rechargeable Lithium Ion Battery Pack (+3.7V, 2150mAh (nominal))
Approximate eight hour continuous operation, with brightness level at 50%
Approximate 80% charge in three hours. 100% charge in less than five
hours.
USB Power Supply Rating 5 VDC, 2A
Operating Voltage (USB input) 4.75 to 5.25 VDC
Operating Altitude Maximum 2000 m
Width 2.9 in. (72.9 mm)
Height 8.9 in. (228.3 mm)
Depth 2.3 in. (58.3 mm)
Weight 8.8 oz. (0.275 kg)
Operating Temperature Range (ambient)
At 0 to 90% relative humidity (non-condensing)
32 to 113°F (0 to 45°C)
Storage Temperature (ambient)
At 0 to 70% relative humidity (non-condensing)
–4 to 140°F (–20 to 60°C)
Environmental Conditions
This product is intended for indoor use only. It is not rated for damp or wet
locations.
This product is rated for Pollution Degree 2 (normal conditions)
