Battery box assembly - 24VDC option
Item Part No Qty Description
1. 3603-06 2 Washer, plain, M6 x 16
2. 3603-08 12 Washer, plain, M8 x 19
3. 3604-06020 2 Screw, M6 x 20
4. 3610-08020 8 Bolt, M8 x 20, C8.8 ZP
5. 3611-06 2 Nut, nylock, M6
6. 3611-08 4 Nut, nylock, M8
7. 3628-08 10 Nutsert, M8
8. 13100 4 Battery, Trojan J305P
9. 13230-10 1 Battery tray, SRxx70
10. 13230-20 1 Battery box lid
11. 13230-30 1 Wrap panel, battery box
12. 13230-40 1 Panel, battery box rear
13. 13230-50 4 Battery J bolt
14. 13230-51 2 Battery hold down angle
15. 057727-000 2 Knob, M8
16. 500052-000 1 Handle
SR3370 & SR2770 – 13184B Rev D page 4 - 13
Battery box assembly - 24VDC option
