Hose Part Numbers and Colour Codes
SR3370 & SR2770 – 13184B Rev D page 2 - 5
Hose Part Numbers and Colour Codes
Colour 1 Colour 2
READING HOSE TAGS
Hose tags are read from the fitting side
of the hose in towards the hose.
As such colour 1 is the closest to the fitting,
colour 2 the next colour then 3, 4 etc…
Snorkel
Part Number
Colour ID
Hose Use
Colour 1 Colour 2
Stab RR Extend: Stab Manifold RRE Z Stab Cyl RR Extend
Red Yellow
Red Green
Orange Yellow
Orange Green
Yellow Yellow
Yellow Green
Green Yellow
Green Green
Blue Yellow
Blue Green
Red ---
Blue ---
Red White
Red Red
Red Blue
Red ---
Orange White
Orange Red
Orange Blue
Orange ---
Yellow White
Yellow Red
Yellow Blue
Green White
Green Red
Green Blue
Green ---
Black ---
Red Orange
Red Black
--- ---
--- ---
Orange ---
--- ---
Black
SR2770 ONLY
Yellow
Black White
Yellow ---
White ---
White Yellow
White White
Black Yellow
Black
Note:
White
SR3370 ONLY
Stab RR Retract: Stab Manifold RRR Z Stab Cyl RR Retract
Stab LR Extend: Stab Manifold LRE Z Stab Cyl LR Extend
Stab LR Retract: Stab Manifold LRR Z Stab Cyl LR Retract
Stab LF Extend: Stab Manifold LFE Z Stab Cyl LF Extend
Stab LF Retract: Stab Manifold LFR Z Stab Cyl LF Retract
Stab RF Extend: Stab Manifold RFE Z Stab Cyl RF Extend
Stab RF Retract: Stab Manifold RFR Z Stab Cyl RF Retract
Steer Right: Main Manifold SR Z Steer Cyl Extend
Steer Left: Main Manifold SL Z Steer Cyl Retract
Drive Forward: Main Manifold DF Z 4WD Manifold DF
Drive Reverse: Main Manifold DR Z 4WD Manifold DR
Motor RR Drain: 4WD Manifold MRRD Z Motor RR Case Drain
Motor RR CW (Fwd): 4WD Manifold MRRF Z Motor RR Port A
Motor RR CCW (Rev): 4WD Manifold MRRR Z Motor RR Port B
Motor RR Brake: Main Manifold BR Z RR Motor Brake
Motor LR Drain: 4WD Manifold MLRD Z Motor LR Case Drain
Motor LR CW (Rev): 4WD Manifold MLRR Z Motor LR Port A
Motor LR CCW (Fwd): 4WD Manifold MLRF Z Motor LR Port B
Motor LR Brake: Main Manifold BL Z LR Motor Brake
Motor LF Drain: 4WD Manifold MLFD Z Motor LF Case Drain
Motor LF CW (Rev): 4WD Manifold MR2 Z Motor LF Port A
Motor LF CCW (Fwd): 4WD Manifold MLFF Z Motor LF Port B
Motor RF Drain: 4WD Manifold MRFD Z Motor RF Case Drain
Motor RF CW (Fwd): 4WD Manifold MRFF Z Motor RF Port A
Motor RF CCW (Rev): 4WD Manifold MRFR Z Motor RF Port B
Lock Left Axle: Main Manifold AXL Z LH Axle Cyl
Lock Right Axle: Main Manifold AXR Z RH Axle Cyl
4WD Manifold Pilot: Main Manifold Pilot Z 4WD Manifold Pilot
4WD Manifold Return: Main Manifold DP Z 4WD Manifold DP
Main Manifold Return: Main Manifold Tank Z Oil Filter Tee
Filter Return: Oil Filter Z Hydraulic Oil Tank
Pump Pressure: Main Manifold Pump Z Pump Pressure Port
Suction Line: Pump Suction Port Z Hydraulic Oil Tank
Raise Stack: Main Manifold LCP Z Lift Cyl Extend
Lift Cyl Drain: Main Manifold LCR Z Lift Cyl Drain
Raise Stack: Main Manifold LCP Z Raise Stack Tee
Lower Stack: Main Manifold LCR Z Drain Stack Tee
Upper Lift Cyl Extend: Raise Stack Tee Z Upper Lift Cyl Extend
Upper Lift Cyl Drain: Drain Stack Tee Z Upper Lift Cyl Drain
Lower Lift Cyl Extend: Raise Stack Tee Z Lower Lift Cyl Extend
Lower Lift Cyl Drain: Drain Stack Tee Z Lower Lift Cyl Drain
12812-74
12812-75
12812-76
12812-77
12812-78
12812-79
12812-80
12812-81
12812-84
12812-85
12812-86
12812-87
12812-88
12812-89
12812-90
12812-91
12812-92
12812-93
12812-94
12812-95
12812-96
12812-97
12812-98
12812-99
12812-100
12812-101
12812-102
12812-103
12812-104
12812-105
12812-106
12812-107
12812-108
12812-109
*12812-116/120
*12812-117/117
*12812-110/110
*12812-111/111
*12812-112/118
*12812-113/113
*12812-114/119
*12812-115/115
Part Numbers marked with an * are shown with the number for STC fittings in black and the number
for JIC fittings in magenta
