Hydraulic assembly
Item Part No Qty Description
0. 12568A 1 Stabiliser valve block assembly
1. 12568-1 4 Stabiliser directional valve
Item Part No Qty Description
0. 13161A 1 Main manifold valve block assembly, V2
1. 12567-1 1 Stabiliser enable valve
2. 12567-2 1 Stabiliser check valve
3. 12567-3 1 Steering flow control
4. 12567-4 1 Steering directional valve
5. 12567-5 1 Steering relief shuttle
6. 12567-6 1 Steering pilot check
7. 12567-2 1 Steering relief check
8. 12567-8 1 Steering relief valve
9. 12567-9 1 Proportional valve
10. 12567-8 1 Lift relief
11. 12567-11 1 Lift valve
12. 12567-12 1 Drive valve, forward
13. 12567-13 1 Drive counterbalance valve, reverse
14. 12567-14 1 Drive check valve, forward
15. 12567-15 1 Free wheel valve
16. 12567-14 1 Drive check valve, reverse
17. 12567-13 1 Drive counterbalance valve, forward
18. 12567-12 1 Drive valve, reverse
19. 12567-19 1 Hand pump
20. 12567-20 1 Brake reset valve
21. 12567-21 1 Brake pilot check
22. 12567-22 1 Brake shuttle
23. 12567-23 1 Axle pressure reducing valve
24. 12567-24 1 Brake flow control valve
25. 12567-11 1 Brake selector valve
26. 12567-2 1 Compensator check
27. 12567-27 1 Compensator bleed, flow regulator
28. 12567-8 1 Main relief
29. 12567-29 1 Compensator
30. 13037 1 Adjustable flow control valve (SR3370 only)
Item Part No Qty Description
0. 13162A 1 4 wheel drive manifold block assembly, V2
1. 12569-1 1 Selector valve series parallel
2. 12569-2 2 Pilot operated selector valves, N.O.
3. 12569-3 2 Flow divider combiner
4. 12569-4 2 Drive motor relief valves
5. 12569-5 2 Pilot operated selector valve, N.C.
page 2 - 2 Rev D SR3370 & SR2770 – 13184B
