Snorkel S3370RT - Flashing Light Installation

Flashing light installation
Item Part No Qty Description
1. 1866-003 1 Flashing light
2. 1866-004 1 Guard, flashing light
3. 3603-05 6 Washer, plain, M5 x 12.5, ZP
4. 3604-05020 3 Screw, pan head, M5 x 20, ZP
5. 3611-05 3 Nut, nyloc, M5
6. 304-0341 2 Terminal pin, male (not shown)
page 4 - 4 Rev D SR3370 & SR2770 – 13184B
Flashing light installation
x3
x3
1
3
3
5
2
4
