Snorkel S3370RT - Battery Box Mounting - 24 VDC Option

Battery box mounting - 24VDC option
Item Part No Qty Description
1. 3610-10100 4 Bolt, M10 x 100, C8.8
2. 3603-10 8 Washer, plain, M10
3. 13233-60 4 Crush spacer
4. 3611-10 4 Nut, nylock, M10
page 4 - 14 Rev D SR3370 & SR2770 – 13184B
Battery box mounting - 24VDC option
x4
1
3
2
2
4
