Page 6-4
Illustrated Parts Breakdown - Chassis Assembly 1 of 3
Chassis Assembly 1 of 3
505001-000
IT E M P AR T NUMBE R DE S C R IP T ION QTY
1 512896-000 C HAS S IS W E LDME NT T M12 1
2 065465-000 B AT T E R Y P AN W E LDME NT 1
3 065472-000 S HOE PAR K B R AK E 2
4 505031-001 BR AK E B E AR ING (R H) & (LH) 2
5 N/A N/A N/A
6 513057-00 0 C HAS S IS AC C E S S P ANE L 1
7 065532-000 F R ONT C OVE R 1
8 510931-000 S P R ING COMP R E S S ION 1
9 065474-000 T E NS ION B AR W E LDME NT 1
IT E M P AR T NUMB E R DE S C R IP T ION QTY
10 SEE PAGE 6-22 C YLINDE R AS S Y (BR AK E ) 1
- SEE PAGE 6-22 S E AL KIT , C Y LINDE R
11 065469-000 BR AK E AC T UAT OR W E LDME NT 1
12 509413-000 GUIDE PAD 2
13 505030-000 S LIDE P AD 2
14 026541-016 HANDLE 1
15 011848-019 PIVOT P IN, B R AK E C Y LINDE R 1
16 065569-000 S P AC E R P LAT E , B AT T E R Y T R AY SEC UR ING P IN 1
17 514746-000 1
8
9
10
15
11
2
14
16
12
13
3
4
6
7 1
17
065536-00
0 MAIN C HAS S IS C OV E R (NOT SHOWN) 1
17 514747-000 2° SIDE TO SIDE OPTION CHASSIS COVER (NOT SHOWN) 1
2° SIDE TO SIDE OPTION BALLAST (NOT SHOWN)
17 510683-025 4M10 X 25 HEX BOLT (NOT SHOWN)
17 510570-010 4M10 SPRING WASHER (NOT SHOWN)
2° SIDE TO SIDE OPTION REPLACES PN : 056536-000
OPTION
