Page 6 - 36 UL25/UL32/UL40
ITEM PART NUMBER DESCRIPTION QTY
1 068201-002 TILTBACK WELDMENT(UL25) 1
2 068180-000 LOADER BAR ASSEMBLY 1
3 068190-000 LOADER STOP BRKT. ASSY. 1
4 514816-000 CASTOR, SWIVEL LOCK (4 x 2) 2
5 068265-000 LIFT TUBE 1
6 062846-001 TUBE - CYL. MOUNT 1
7 063926-004 CAP PLUG 1
8 062844-000 LIFTBAR WELDMENT 1
9 062843-001 GRIP SLEEVE 1
10 003570-005 RETAINING PIN ASSY. 1
11 011256-022 HEX HD BOLT - 1/2" UNC x 2.75 2
12 011248-008 NUT - 1/2-13 UNC 2
13 986269 FLAT WASHER - 5/16" 16
14 970269 HEX. HD. BOLT - 5/16"-18 x 1.25" 8
15 5560031 NYLOCK NUT - 5/16"-18 8
16 062891-001 LANYARD ASSEMBLY 1
17 5592006 EXTERNAL CIRCLIP - 19mm 2
18 068190-000 LOADER STOP BRACKET ASSY 1
19 062891-001 LANYARD ASSEMBLY 1
20 011248-008 Nut HEX ESNA 1/2-13 UNC 4
21 011256-022 SCREW HHC 1/2 - 13 2(3/4) 2
Table 6-18b: UL25 tilt back assembly components.
TILT BACK ASSEMBLY -
UL25 - 068200-003
