SPECIAL LIMITATIONS
SPECIAL LIMITATIONS
Elevating the work platform is limited to rm, level surfaces only. This machine is rated for indoor
use only. All four outriggers must be properly installed before operating the machine.
!
D A N G E R
!
The elevating function shall ONLY be used when the work platform
is levelled and on a rm surface. DO NOT attempt to move this
machine with the mast in an elevated position. The machine weighs
in excess of 760 lb (345 kg) and must only be manoeuvered on rm,
level ground.
PLATFORM CAPACITY
The platform capacity for the machine including occupants is determined by model and options.
This is listed under “specications”.
!
D A N G E R
!
DO NOT exceed the maximum platform
occupancy limits for this machine
MANUAL FORCE
Manual force is the force applied by the occupants to objects such as walls or other structures out-
side the work platform. The maximum allowable manual force is limited to 200N (45 lbs.) of force.
!
D A N G E R
!
DO NOT exceed the maximum amount of
manual force for this machine.
LIFT LEVEL SENSOR INTERLOCK
The platform lift function is interlocked through a level sensor system. If the chassis is tilted more
than 1.5 degrees in either direction, an alarm will sound when the power is turned on and the lift
function will not operate. When the alarm sounds, only the platform lower function will operate.
