Page 3 - 19UL25/UL32/UL40
FASTENERS
Use the following values to torque fasteners used on Snorkel work platforms unless a specic torque
value is called out for the part being installed.
Thread size (American National
Standard-UNF (ne))
Width across ats Torque value
Imperial Metric
1/4 7/16 110 IN/Lbs 12 Nm
5/16 1/2 190 IN/Lbs 22 Nm
3/8 9/16 30 Ft/Lbs 41 Nm
7/16 5/8 50 Ft/Lbs 68 Nm
1/2 3/4 75 Ft/Lbs 102 Nm
5/8 15/16 150 Ft/Lbs 203 Nm
3/4 1(1/8) 250 Ft/Lbs 339 Nm
7/8 1(5/16) 400 Ft/Lbs 542 Nm
1 1(1/2) 600 Ft/Lbs 813 Nm
SERVICE AND REPAIR
Table 3-5: Bolt Torque.
