Page 6 - 14 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
DC LOWER CONTROL BOX - 514443-000
ITEM PART NUMBER DESCRIPTION QTY
1 514437-000 UL DC Lower control box weldment 1
2 514895-000 EZ120 controller 1
3 514438-000 UL DC lower control box panel 1
4 0120804 Push button; Schneider XB2BA3351C 1
5 0120803 Push button; Schneider XB2BA3341C 1
6 510542-000 Pushbutton; Schneider XB2BA21C 1
7 510524-000 SW twist release E/stop 1
8 512543-000 Keyswitch 3 position stayput 1
9 513949-000 9 way chassis socket 1
10 514433-000 7 way chassis socket 1
11 514435-000 5 way chassis socket 1
12 502588-000 Alarm, ECCO beeping 6-28 VDC 1
13 446086 Fuse holder 1
14 513876-000 FSHCS M5 x 0.8 x 25 class 8.8 DIN7991 2
15 056067-008 M8 nut - 8 4
16 510156-000 9 way panel plug 1
17 510157-000 12 way panel plug 1
18 505082-014 M5 x 14 skt button cap screw DIN9427 4
19 509755-000 Mate - n - lock SCKT contact 22
20 514441-001 Overlay 1
21 446076 Fuse 250 A 1
22 510561-008 M8 washer - ST/ST 2
23 056064-006 M6 nylock nut 2
24 058502-035 M6 x 35 S.H.C.S. - GR 8.8 2
25 509741-000 Blade fuse holder 1
26 509740-005 Blade fuse 7.5 A 1
27 514642-000 Socket 4-way panel mount 1
28 512935-000 LED green 12 V 1
29 510145-000 Mate - n - lock pin contact 4
30 512366-000 4 way panel plug 1
Table 6-6: DC Lower control box components.
