Snorkel UL40 - Lift Cylinder Components

Page 6 - 16 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
LIFT CYLINDER
UL25 - 068074-020
UL32 - 068074-021
UL40 - 068074-022
ITEM PART NUMBER DESCRIPTION UL25 UL32 UL40
1 068129-000 3
rd
stage bottom casting 1 1 1
2 068128-000 2
nd
stage bottom casting 1 1 1
3 068113-006 Lift cylinder 1
068113-007 Lift cylinder 1
068113-008 Lift cylinder 1
068113-010 Seal kit
4 068076-000 Cylinder sheave 2 2 2
5
062164-000 Chain 2
062164-123 Chain 2
062164-149 Chain 2
6 068089-000 Cylinder mount 1 1 1
7
068080-001 Tie rods 2
068080-002 Tie rods 2
068080-003 Tie rods 2
8 011248-010 Locknut 5/8 -11 UNC 2 2 2
9 068079-000 Cylinder guide bearing 2 2 2
10 011737-010 Roll pin 1 1 1
11 068081-000 Pin cylinder 1 1 1
12 011764-023 Retaining ring 1 1 1
13 062642-022 Bearing 16DU16 2 2 2
14 062169-004 Master link 2 2 2
15 062655-001 Chain guard 2 2 2
16 011941-005 Fitting ST O-ring 6MB - 6MJ 1 1 1
17 011828-006 Screw Flat HD socket 1/4 - 20 x 3/4 2 2 2
18 068143-000 Chain pin 2 2 2
19 011240-002 Washer #8 at 4 4 4
20 026553-008 Rivet 3/16 4 4 4
21
060861-115 Hydraulic hose 1
060861-011 Hydraulic hose 1
060861-011 Hydraulic hose 1
22 011737-010 Roll pin 1/4 x 1 - 1/4 1 1 1
23 063988-006 Shim 1 1
24 066179-001 Valve, Lowering 1 1 1
25 069040-000 Threaded stud 1/4 - 28 x 1 1 1 1
26 069041-000 Knob - Red 1 1 1
Table 6-7: Lift cylinder components.
