Page 6 - 26 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
PLATFORM SUPPORT ASSEMBLY
UL25 - 514599-000
UL32 - 514599-010
UL40 - 514599-011
ITEM PART NUMBER DESCRIPTION UL25 UL32 UL40
1
514599-001 Platform support weldment 1
514599-002 Platform support weldment 1
514599-003 Platform support weldment 1
2
062165-133 Chain 2
062165-169 Chain 2
062165-201 Chain 2
4 017301-005 Tube 1/2 OD x 18 GA wall x 7/8 2 2 2
5 068092-000 Sleave spanner tube 1 1 1
6 068093-000 Roller chain 1 1 1
7 068094-0041 Control cable sheave 2 2 2
8 068162-000 Control cable sheave bracket 2 2 2
9 062753-001 Strap assy 1 1 1
10 068049-000 Control bracket 1 1 1
12 011254-010 Screw HHC 3/8 - 16 UNC x 1(1/4) 2 2 2
13 011240-006 Washer 3/8 STD at 2 2 2
14 011250-006 Nut hex ESNA 3/8 - 16 UNC 2 2 2
16 068142-000 Chain pin 2 2 2
17 011253-006 Screw HHC 5/16 - 18 UNC x 3/4 2 2 2
18 011240-005 Washer 5/16 STD at 2 2 2
19 011250-005 Nut hex ESNA 5/16 - 18 UNC 2 2 2
20 011252-008 Screw HHC 1/4 - 20 UNC x 1 4 4 4
21 011240-004 Washer 1/4 STD at 11 11 11
22 011248-004 Nut hex ESNA 1/4 - 20 UNC 6 6 6
23 014099-044 Screw HHC 3/4 - 10 UNC x 5(1/2) 1 1 1
24 011248-012 Nut hex ESNA 3/4 - 10 UNC 1 1 1
25 068231-000 Top cover 1 1 1
26 011240-012 Washer STD at 3/4 2 2 2
27 011252-003 Screw HHC 1/4 - 20 UNC x 3/8 3 3 3
28 062129-000 Strap retainer 1 1 1
29 012553-005 Screw SOC HD 1/4 - 20 UNC x 5/8 2 2 2
30 063926-007 50 x 50 insert 2 2 2
Table 6-13: Platform support assembly components.
