Page 6 - 28 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
PLATFORM ASSEMBLY - UL25
068179-003
ITEM PART NUMBER DESCRIPTION QTY
1 068082-001 Platform support weldment 1
2 068123-000 Slide angle 4
3 506275-001 Rail weldment (ANSI Lower rail 068150-002) 1
4 068149-002 Cage pan 1
5 068276-000 Shear guard 1
6 068096-000 Rail bearing top 4
7 068147-000 Front cover 1
8 057524-001 Drop bar assy 1
9 026525-003 Screw SLFTP #8 HWH x 3/8 16
10 970109 Screw HHC 1/4 - 20 UNC 2 x 3/4 2
11 011240-004 Washer 1/4 STD 15
12 011248-004 Nut hex ESNA 1/4 - 20 UNC 12
13 011264-022 Screw HHC 5/16 - 18 UNC x 2(3/4) 4
14 011240-005 Washer 5/16 STD 4
15 011246-010 Nut ESNA 5/16 - 18 UNC 4
16 510524-000 Switch, push pull 1
17 510525-000 Contact block 1
18 062799-011 Enclosure box & cover 1
19 0120803 Push button up 1
20 510527 Contact block N.O. 3
21 0120804 Push button down 1
22 510542 Push enable 1
23 029925-000 Connector 1
24 029939-002 Locknut 1/2 NPT 1
25 014252-004 Nut sert 1/4 - 20 UNC 3
26 011825-006 Screw RND HO 1/4 - 20 UNC x 3/4 5
27 011708-003 Screw RD HO mach #8-32 x 1/2 2
28 011252-014 Screw HHC 1/4 - 20 UN x 1 3/4 4
29 014924-008 U-bolt 2
30 068630-000 Extension spring Ø 0.055 wire 2
31 013919-009 Clamp, 5/8 DIA. 4
32 026551-007 Rivet 1/8 .251-.312 grip 4
33 057094-002 Harness hardpoint bracket 1
34 514696-000 Backing plate 1
35 514697-000 Backing plate 2
36 058508-030 Bolt - M10 x 30 1
37 056064-010 Nyloc nut - M10 1
38 505087-010 Flatwasher - M10 2
39 970129 Screw HHC 1/4 - 20 UNC x 3 2
Table 6-14: Platform assembly components UL25.
