Page 6 - 30 UL25/UL32/UL40
ILLUSTRATED PARTS LIST
PLATFORM ASSEMBLY - UL32/UL40
068179-004
ITEM PART NUMBER DESCRIPTION QTY
1 068082-001 Platform support weldment 1
2 068123-000 Slide angle 4
3 506275-001 Rail weldment (ANSI Lower rail 068150-002) 1
4 068149-002 Cage pan 1
5 068096-000 Rail bearing top 4
6 068147-000 Front cover 1
7 057524-001 Drop bar assy (ANSI upper rail 068171-002) 1
8 026525-003 Screw SLFTP #8 HWH x 3/8 16
9 970109 Screw HHC 1/4 - 20 UNC x 2(3/4) 2
10 011240-004 Washer 1/4 STD 15
11 011248-004 Nut Hex ESNA 1/4 - 20 UNC (ANSI rail only) 12
12 011264-022 Screw HHC 5/16 - 18 - UNC x 2 3/4 4
13 011240-005 Washer 5/16 STD 4
14 011246-010 Nut ESNA 5/16 - 18 UNC 4
15 510524-000 Switch, push pull 1
16 510525-000 Contact block 1
17 062799-011 Enclosure box & cover 1
18 0120803 Push button up 1
19 510527 Contact block N.O. 3
20 0120804 Push button down 1
21 510542 Push enable 1
22 029925-000 Connector 1
23 029939-002 Locknut 1/2 NPT 1
24 014252-004 Nut sert 1/4 - 20 UNC 3
25 011825-006 Screw RND HO 1/4 - 20 UNC x 3/4 5
26 011708-003 Screw RD HO mach #8 - 32 x 1/2 2
27 011252-014 Screw HHC 1 14 - 20 UNC x 1 3/4 4
28 014924-008 U - bolt 2
29 068630-000 Extension spring Ø 0.055 wire 2
30 013919-009 Clamp, 5/8 diameter 4
31 057094-002 Harness hardpoint bracket 1
32 514696-000 Backing plate 1
33 514697-000 Backing plate 2
34 058508-030 Bolt - M10 x 30 1
35 056064-010 Nyloc nut - M10 1
36 505087-010 Flat washer - M10 2
37 970129 Screw HHC 1/4 - 20 UNC x 3 2
Table 6-15: Platform assembly components UL32/UL40.
