socomec NETYS RT - Page 38

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC
38
EN
3
Carefully lift the whole unit upright
4
with the Socomec logo nameplates and
the icons shown on the panels facing up.
4
Place the whole unit inside the tower stands
5
.
Leave adequate space (at least 50cm) around all sides of the unit for good ventilation.
A minimum of two people are required to execute
3
and
4
.
Lift up 90°
(Figure 6-6: Place the Whole Unit Upright)
4
(Figure 6-7: Place the Whole Unit inside the Tower Stands)
5
