socomec NETYS RT - REAR PANEL

NETYS RT Hot Swap 7 - 11 kVA - 551574B - SOCOMEC
23
EN
4. REAR PANEL
Model: NRT3-7000MBP
P2
P3
P4P1
WARNING:
OPENING THIS COVER PLATE WILL CAUSE
INVERTER SHUTDOWN.
ONLY AUTHORIZED SERVICE PERSONNEL
CAN OPEN AND OPERATE IT.
NORMAL
N L
AC INP UT
N L
UPS OUT PUT
SMART SLOT
RS-232
MANUAL BYPASS SWITCH
OUTPUT
BREAKER-2
250V AC 25A
OUTPUT
BREAKER-3
250V AC 20A
OUTPUT
BREAKER-4
250V AC 20A
OUTPUT SOCKET-4 / 10A MAX. PER OUTLET
OUTPUT SOCKET-3 / 10A MAX. PER OUTLET
OUTPUT SOCKET-2 / 16A MAX. PER OUTLET
EXTERNAL BATT. CONNECTOR 192V DC 35A
OUTPUT BREAKER-1
250V AC 20A
POWDER SHARE OUTPUT
16A MAX – SOCKET-1
DRY CONTACT RS-485REPO
N L
A C I N P UT
N
L
UPS O U T P UT
TMOV
1 2 3
4 5 6
7
7
9 8
10
11
12
14
16
13
15
(Figure 4-1: 7 kVA Rear Panel)
Model: NRT3-11000MBP
SMART SLOT
MANUAL BYPASS SWITCH
EXTERNAL BATT. CONNECTOR 240V DC 46A
OUTPUT SOCKET-4
10A MAX. PER OUTLET
OUTPUT SOCKET-3
16A MAX. PER OUTLET
OUTPUT BREAKER-2
250V AC 25A
OUTPUT SOCKET-2
16A MAX. PER OUTLET
OUTPUT BREAKER-3
250V AC 25A
OUTPUT BREAKER-4
250V AC 20A
OUTPUT BREAKER-5
250V AC 20A
OUTPUT SOCKET-5
10A MAX. PER OUTLET
P2
P3
P4P1
RS-232
DRY CONTACT RS-485REPO
OUTPUT BREAKER-1
250V AC 20A
WARNING:
OPENING THIS COVER PLATE WILL CAUSE
INVERTER SHUTDOWN.
ONLY AUTHORIZED SERVICE PERSONNEL
CAN OPEN AND OPERATE IT.
NORMAL
UPS OUT PU T
L N
AC INP UT
N L
TMOV
POWDER SHARE OUTPUT
16A MAX – SOCKET-1
1 2 3
4 5 6 77
89
12
13
14
16
15
11
10
(Figure 4-2: 11 kVA Rear Panel)
