- 11 -
SR4 MANUAL
6
-
2 DISTANCE BETWEEN THE REAR AXLE AND THE MIDDLE OF THE ROUND REAR
EDGE OF THE SEAT.
6-3 DISTANCE BETWEEN THE AXIS OF THE LEFT SIDE STUB AXLE FORK AND THE
MIDDLE OF THE REAR ROUNDED EDGE OF THE SEAT.
Measure from the
middle of the
rounded edge.
220 mm
11
13
Table of Contents
Default Chapter
2
Table of Contents
2
Safety Instructions
4
Preparing the Assembly
5
1- Getting Sr4 out of the Packing
5
2- Tools for Assembly
6
3- Maintenance Products
6
Sequence of Assembly
7
4- Assembly of the Steering Column and of the Steering Wheel
8
5- Assembly of the Fuel Tank and of the Overflow Bottle
10
6- Assembly of the Seat and of the Seat Stiffeners
11
7-Assembly of the Kg Unico Body Work
14
8- Assembly of the Sodi Body Work
17
9- Starting Your Sr4
21
10- Table of the Standard Adjustments
22
11- Adjustment of the Front End
23
Standard Adjustments
26
12- Adjustment of the Rear End
29
13- Adjustment of the Seat
32
Maintenance
33
14- Tyres
33
15- Brake Pads Replacement
35
16- Bleeding of the Brake System
36
17- Cleaning the Chassis
37
18- Maintenance Plan
38
19- Trouble Shooting
39
